Difference between Dependency Injection and Factory Design Pattern in Java Spring

Learning a Programming language like Java or Python is easy, but writing production-quality code is difficult. Coding is as much art the Science behind it. To write good code, you need to carefully design your classes, their dependency, and how to use that. This is important so that it can survive the constant change throughout his lifetime. If you have been coding for some time, then you know that SOLID principles and Design Patterns help you to write better code. This is obvious because they are proven the solution to some common problems software developers face all around the world. But, knowing just the design pattern is not enough, you also need to learn using the right design pattern in the right place.

In this article, we are going to look at two design patterns, the Factory pattern and Dependency Injection and learn the difference between them so that you can develop the coding sense for their effective use.

Btw, if you are here to know the answer of dependency injection vs. factory pattern then let me tell you that the main difference between dependency injection and factory pattern is that in the case of former dependency is provided by the third party (framework or container) while in the case of later dependency is acquired by client class itself.

Another key difference between them is that use of dependency injection results in loosely coupled design, but the use of factory pattern creates a tight coupling between factory and classes which are dependent on the product produced by the factory.

Btw, If you are serious about learning design patterns and principles, I suggest you take a look at the Design Patterns in Java course on Udemy.  This course covers both SOLID design principles like Open Closed and Liskov substitution, and all-important Object Oriented design patterns like Decorator, Observer, Chain of Responsibility, and much more.





Factory Pattern vs. Dependency Injection

Though both Dependency Injection and Factory pattern look similar in a sense that both creates an instance of a class, and also promotes interface driven programming rather than hard-coding implementation class,  there are some subtle differences between the Factory pattern and Dependency injection pattern, which we'll discuss next.

In the case of Factory design pattern, client class is responsible for calling getInstance() of factory class to create an instance of products, it also means that client class is directly coupled with the factory and can't be unit tested without factory class being available.

On the other hand, in Dependency Injection, client class has no clue about how his dependencies are created and managed. It only knows about dependencies.

Mostly dependencies are injected by a framework like a bean class exists without any hard-coded dependency, as those are injected by IOC container like Spring Framework.

You can also use points discussed here to answer questions like the difference between Spring IOC and Factory pattern because Spring IOC is nothing but an implementation of dependency injection pattern.

If you want to learn more about how exactly dependency injection works in Spring, I suggest you join a comprehensive Spring course like Spring Framework 5: Beginner to Guru by John Thompson on Udemy. It is also most up-to-date and covers Spring 5 and Reactive programming.

Dependency Injection and Factory Design Pattern in Java Spring





Dependency Injection vs. Factory Pattern in Code

To understand the difference between factory pattern and dependency injection better, let's see examples of how both DI and Factory design pattern are used :

1. Factory Pattern Code Example

public class CashRegister {

    private PriceCalculator calculator = PriceCalculatorFactory.getInstance();

    public void add(Transaction tx) {
          int price = calcualtor.getPrice(tx);
          add(price);
    }

}

In this case dependent class, CashRegister is directly coupled with PriceCalculatorFactory because its calling static gets Instance() method from PriceCalculatorFactory to satisfy its dependency. In order to test CashRegister, you must need a PriceCalculatorFactory, which is not suitable for unit testing of this class.

On the other hand, if you use Dependency injection, then dependencies are added by frameworks like Spring framework or DI container like Google Guice because you reverse the responsibility of acquiring dependencies.

Now it's the responsibility of IOC container to inject dependency than the dependent class fending for himself. In the case of dependency injection, any class just looks like a POJO.

2. Dependency Injection Code Example

public class CashRegister {

    private PriceCalculator calculator;

    public CashRegister(PriceCalculator calculator){
        this.calculator = calculator;
    }

    public void add(Transaction tx) {
          int price = calcualtor.getPrice(tx);
          add(price);
    }

    public void setCalcuator(PriceCalculator calc){
        this.calculator = calc;
    }

}

You can see that dependency for CashRegister, which is PriceCalculator is supplied via a constructor, this is known as constructor dependency injection.

There is another form of DI as well, e.g. setter injection, in which dependency is provided using a setter method.

For example, setCalcuator(PriceCalcuator) is facilitating setter injection there. You should use constructor injection to inject mandatory dependencies and setter injection for optional, good to have dependencies.

If you want to learn more about Setter vs. Constructor Injection, particularly from Spring Framework point of view, which supports both of them, I suggest you take a look at the Spring Master Class - Beginner to Expert course. Another great course to learn and master Spring online by yourself.


Dependency Injection vs Factory Design Pattern in Java Spring





Difference between Factory Pattern vs. Dependency Injection

Based on our knowledge of both of these patterns, you can easily deduce the following key differences between them :

1) Factory pattern adds coupling between object, factory, and dependency. Object not only needs a dependent object to work properly but also a Factory object. While in case of dependency injection, Object just knows the dependency, it doesn't know anything about container or factory


2) As compared to the Factory pattern, Dependency injection makes unit testing easier. If you use the factory pattern, you need to create the object you want to test, the factory and the dependent object, of course, you factor can return a mock object, but you need all this just to start with unit testing.  On the other hand, if you use dependency injection, you just need to mock the dependency and inject into an object you want to test, no clutter or boilerplate is required.


3) Dependency injection is more flexible than the factory pattern. You can even switch to different DI frameworks like Spring IOC or Google Guice.


4) One of the drawbacks of Dependency injection, as compared to Factory pattern, is that you need a container and configuration to inject the dependency, which is not required if you use a factory design pattern.

In a real sense, it's not such a bad thing because you have one place to see the dependency of your class and you can control them, but yes when you compare DI to a factory method, this is the additional step you need to do.


5) Due to low coupling, DI results in much cleaner co than factory pattern. Your object looks like POJO, and you also come to know what is mandatory and what is an option by looking at which type of dependency injection your class is using.

If an object is injected using Setter injection, which means it's optional and can be injected at any time, while dependencies which are injected using constructor injection means they are mandatory and must be supplied in the order they are declared.


6) Another tricky scenario with using DI is creating an object with too many dependencies and worse if those are injected using constructor injection.

That code becomes difficult to read. One solution to that problem is to use the Facade pattern and inject dependencies by encapsulating in another object.  For example, you can introduce an object say ApplicationSettings, which can contain DatabaseSetting, FileSetting, and other configuration settings required by an object. You can read more about Facade pattern in the Design Pattern Library course on Pluralsight, which is one of the best collection fo design patterns in one place.


7) You should use Dependency Injection Patterns to introduce loose coupling. Use Factory Patterns if you need to delegate the creation of objects. In short, dependency injection frees your application from factory pattern boilerplate code.

All the work which is required to implement a factory is already done by IOC containers like Spring and Google Guice.


And, here is an excellent summary of some key differences between the Factory Pattern and Dependency Injection pattern in Java and OOP:


Difference between Factory pattern and dependency injection


That's all between the difference between a Factory design pattern and dependency injection in Java. Both patterns take out the creation of dependencies from the dependent class and encourage the use of interfaces for defining a property, e.g. here we are using PriceCalculator which is an interface so that it can later be replaced by any suitable implementation without affecting any part of the code.

The real difference between factory and dependency injection lies on the fact that in the case of a factory, your dependent class is still reliant on a factory, which is a new form of dependency while DI takes out the dependency completely.

This means dependency injection provides better decoupling and unit testing of classes over Factory design pattern.


Further Learning
Design Pattern Library
From 0 to 1: Design Patterns - 24 That Matter - In Java
Java Design Patterns - The Complete Masterclass


If you like this article and interested in learning more about design patterns and principles, you may like following ones as well :
  • 5 Free Courses to learn Object Oriented Programming (courses)
  • What is the difference between Adapter, Decorator, and Proxy design patterns? (answer)
  • How to implement the Builder design pattern in Java? (solution)
  • 10 Object-Oriented Design Principle Every Programmer Should know (principles)
  • What is Open Closed design Principle in OOP? (answer)
  • What is the difference between Factory and Abstract Factory Design Patterns? (answer)
  • 5 Reasons to use Composition in place of Inheritance in Java? (answer)
  • How to implement the Strategy Design Pattern using Java Enum? (solution)
  • What is the difference between State and Strategy Pattern in Java? (answer)
  • Top 5 Books to Learn Design Patterns and Principles (books)
  • How to implement DAO design Pattern in Java? (answer)
  • Why implementing Singleton using Enum is better than Class in Java? (answer)
  • What is the difference between Association, Aggregation, and Composition in OOP? (answer)
  • What is the difference between Singleton and Static Class in Java? (answer)
  • Why should you Interface for Coding in Java? (answer)
  • A real-life example of the Decorator Pattern in Java? (example)
  • 5 Online Courses to learn Design Pattern in Java (courses)

Thanks for reading this article so far. If you like this article about the Factory design pattern and Dependency Injection pattern in Java, then please share with your friends and colleagues. If you have any questions or feedback, then please drop a note.
